Capping extruder 100kg/h

Model: WP100
The cappings extruder with capacity up to 100kg per hour is your number 1 choice if you desire to raise your apiary efficiency! The cappings extruder screw squeezes the cappings and as a result, liquid honey is coming out through the perforated cylinder. Based on feedback from beekeepers and our own long-time experience, we can surely say that the cappings extruder with production power of 100 kg/h has the most optimal power for both a novice beekeeper and a big honey producer.
3050€ 2500€ (without VAT)
Send an inquiry!

  • Device manufactured in Estonia
  • 5-year warranty
  • Reliable quality

The capping extruder is designed to squeeze out the last drop of honey out of the wax cappings.

Capping extruder fits perfectly under the uncapping machines produced by Asten Honey production & technology

Speed is adjusted easily with frequency converter up to 8 rpm. Also has the possibility to us reverse function

The working parts of the device that come into contact with honey are made of stainless steel.

Capping extruder screw is made of reinforced plastic suitable for the food industry.

The frame of the device is made of metal and painted with abrasion-resistant powder paint.

Technical specifications

  • Power supply 230 V
  • Tramac motor 0.55kw
  • Hypoid reductor
  • Frequency converter 0.75kW
  • Total power 1500W
  • Speed control function
  • Reverse function
  • Stainless steel ball valve 1 ¼“

Device dimensions:

  • Screw diameter 120mm, length 900mm
  • The entire length from the tap to the control panel (if the control panel is mounted on the rear end of the machine1400mm
  • Height 770mm
  • Device width 400mm
  • Total width of the device (with the wax collector on it) 615mm
  • Wax collector size 600x616mm
  • wax collector depth 200mm

Manual

EN_Tigupress-100kg-kasutusjuhend

Video
